Banding machine Easy Band 45

In stock

REQUEST QUOTE NOW



The Easy Band 45 is a simple and reliable table top banding machine. It can guarantee a wrapping speed of 25 cycles / min and can use paper and polypropylene tapes between 20/30 mm wide. Its maximum banding light is equivalent to L 423 x H 158 mm.

WEIGHT
33 kG

POWER SUPPLY
220 V

BANDING TYPE
FILM IN PE/OPP

VARIOUS TYPE PRODUCTS BAND



Automatic banding machine that uses paper and polypropylene tapes

Automatic banding machine, Mod. Easy Band 45, simple and reliable, uses paper and polypropylene bands of 30 mm width. and length 190 mt. Maximum arch dimension of banding mm. 460 x 200 h.Speed up to 25 cycles per minute. The tension of the band is adjustable using a screw placed inside the machine. Manual or automatic functioning by sensor.

The banding machine Easy Band 45, in addition to the classic use in graphic arts, bookbinding and converting industries, is particularly suitable for the construction of multi-packs or for the matching of multiple products in promotional sales.

Available with motorized reel holder mod. Easy Band 45B, allows the use of the band rolls with lenght 500 mt. with a considerable saving of time and cost of the bands.

FEATURES AND USE

USE
Selecting the automatic mode and just placing the product on the worktable of the banding machine, the banding and
sealing cycle is activated by a photocell that reads the product. When the product is removed, the machine re-feeds
the band and prepares itself for the next banding. Selecting the manual cycle, the operator starts a manual banding by
button. The replacement of the band roll is quick and easy.
FEATURES
  • Compact design
  • Coil holder inside the machine
  • Digital display
  • Parameters adjustable by control panel
  • Removable worktable for a fast maintenance
  • Banding head with 24 vcc motors
  • Band tensioning adjustable by screw
  • Manual or automatic banding by sensor
  • Adjustable welding time
  • Adjusttable time between one banding and another (only auto mode)
  • Adjustable out feeding time of the band
  • Language selection
  • The machine complies with CE directives

fascettatrici; elettrica; tavolo; elettriche; automatiche; reggiatura; reggiatrici; fascette;

REQUEST A FREE QUOTE NOW

SAVE TIME! Make a request to receive our best offer on this product. Alternatively, for more information, you can always contact us at +39.06.9160.7561.

Additional information

Machine dimensions

L 600 x W 364 x H 474 mm

Net weight

33 Kg.

Power supply

220 Volt

Power supply frequency

50/60 Hz

Maximum noise

Conforming to DIN 45635/27

Production capacity

25 cycles

Coil holder

Integrated

Band type

Film in PE/OPP (polipropilene)

Band widht

20 – 30 mm

Band thickness

100 – 120 my

Banding tension

5 – 40 N

Closing system

Thermal welding

Film roll internal diameter

40 mm

Film roll external diameter

Max. 180 mm

Banding arch size

L 473 x H 208 mm

Dimension Min. product

W 30 x H 10 mm

Max product size

L 423 x H 158 mm
