Easy Strap 309B – 312B

In stock

REQUEST QUOTE NOW



Automatic strapping machine with operator model Easy Strap 309 - 312. Uses 9 or 12 mm PP strap. Robust and compact, designed for general use and medium-high work volumes. 180 ° rotating control panel to work on both sides of the machine. Bar strapping pedal to facilitate cycle start-up. Available on request with various measures of strapping arches.



Caratteristiche reggiatrice automatica Easy Strap 309B

Automatic strapping machine with motorized belts on the work surface

The Easy Strap B series strapping machine is a compact, reliable, solid and easy to use machine. Thanks to its characteristics it can be inserted in fully automated production lines ensuring medium-high work volumes. The worktop is made of motorized conveyor belts and it has a system of photocells for the automatic execution of 1-2 or multiple straps, which can be managed through the analog control panel, which has a 180 ° rotating system to work on both sides of the machine. It works with DC motors arranged for each function of the machine.In addition to the SUS 304 stainless steel versions, it is also available with a pneumatic stabilizing press version.

Caratteristiche generali della reggiatrice

The Easy Strap 309B and 312B automatic strapping machine use a 220 V power supply | 1 ph | 50/60 Hz and has an adjustable worktop height from H 850 – 950 mm. It has a strapping speed of 40 cycles per minute with a maximum adjustable tensioning force up to 45 Kg. The strapping machine is equipped with four pivoting wheels, two of which with brakes and an easyfast® strap guide disassembly system (without tools). There is also: automatic ejection of a piece of strap at the end of the reel, adjustment of the welding cooling time (COOL TIME), temperature adjustment of the sealing blade, strap cutting cutter, automatic strap loading system, magnetic safety sensors and top with motorized belts adjustable in speed by means of a potentiometer. The strapping machine is available on request with various arch sizes.

Layout reggiatrice automatica Easy Strap 309B - 312B

Features and parameters of the strapping machine

Technical features
  • Working table with motorized conveyor belts
  • Stainless steel protective handle
  • Safety systems on opening working table and doors
  • Automatic loading of the strap
  • Single, double or multiple strapping system through photocells
  • Strapping adjustment by control panel
  • Enabling and disarming motorized conveyor belts
  • Transit mode without strapping the product
  • Adjustment of conveyor belts speed on working table through potentiometer
  • Acustic alarm system with 3-color flashing column
  • Emergency stop button
  • Ejection loop in case of accidentally start of the cycle
  • 180 ° rotable control panel
  • Strap cutter
  • Height-adjustable working table
  • Automatic strap ejection
  • Re-feed strap system
    Possibility of using various strap sizes
Parametri regolabili da quadro comandi
  • Weld cooling time adjustment (COOL TIME)
  • Strap tension adjustment via potentiometer
  • Belt speed adjustment on the work surface by means of a potentiometer
  • Temperature adjustment of the sealing blade
Product features
  • Max. Product dimensions: L 550 x H 450 mm.
  • Product weight: 80 Kg.
Strap roll features

Internal diameter: 200 – 210 mm.


External diameter: 400 – 500 mm.

Strap width: 9 – 12 mm.

Strap thickness: 0,45 – 0,65 mm.
Strap type: PP (polipropilene)

Scarica la scheda tecnica della reggiatrice

REQUEST A FREE QUOTE NOW

Make a request to receive our best offer on this product. Alternatively, for more information, you can always contact us at 06.9160.7561.

Additional information

Power supply

220 Volts

Power supply frequency

50/60 Hz

Installed power

1 Kw

Machine dimensions

L 1580 x W 720 x H 1460 – 1940 mm.

Dimension strapping arch size

L 650 x H 500 mm, L 850 x H 500 mm., L 850 x H 600 mm., L 850 x H 800 mm.

Strapping speed

40 cycles/min.

Tension strength

0 – 45 Kg

Type

Motorized belts

Control panel

Analog control panel

Max product weight

80 Kg

Reel internal diameter

200 – 210 mm.

Coil outer diameter

400 – 450 mm.

Strap width

9 – 12 mm

Strap thickness

0,45 – 0,65 mm

Strap type

PP (polypropylene)
