Easy Strap 309R – 312R

In stock

REQUEST QUOTE NOW



Automatic strapping machine with motorized steel roller conveyor. Thanks to its configurations it is possible to insert it in fully automated production lines. It works with direct current motors arranged for each function of the machine. Possibility to carry out multiple, double or single strapping through a photocell reader. Uses 9 or 12 mm PP strap. Robust and compact, designed for general use and medium-high work volumes. Through the control panel it is also possible to configure it in transit mode without strapping the products.



Parametri reggiatrice Easy Strap 309R - 312R

Automatic strapping machine with motorized steel roller conveyor

The Easy Strap R series strapping machine is a compact, reliable, soldi and easy to use machine. Thanks to its characteristics it can be inserted in fully automated production lines ensuring medium-high work volumes. The working table is made up of motorized steel rollers and a system of photocells for the automatic execution of 1-2 or multiple straps, which can be managed through the analog control panel, which adopts a 180 ° rotating system to work on both sides of the machine. It works with direct current motors arranged for each function of the machine. Compared to a traditional strapping machine, more than 30% of mechanical components have been eliminated. In addition to the SUS 304 stainless steel versions, it is also available with a pneumatic stabilizing press

General characteristics of the strapping machine

The Easy Strap 309R and 312R automatic strapping machine use a 220 V power supply | 1 ph | 50/60 Hz and has an adjustable worktop height from H 850 – 950 mm. It has a strapping speed of 30 cycles per minute with a maximum adjustable tensioning force up to 45 Kg. The strapping machine is equipped with four pivoting wheels, two of which with brakes and an easyfast® strap guide disassembly system (without tools). There is also: automatic ejection of a piece of strap at the end of the reel, adjustment of the welding cooling time (COOL TIME), temperature adjustment of the sealing blade, strap cutting cutter, automatic strap loading system, magnetic safety sensors and top with motorized belts adjustable in speed by means of a potentiometer and motorized steel rollers. The strapping machine is available on request with various arch sizes.

Layout reggiatrice automatica Easy Strap 309R

Features and parameters of the strapping machine

Technical characteristics of the strapping machine
  • Working table with motorized steel rollers
  • Stainless steel protective handle
  • Safety system on opening working table and doors
  • Automatic loading of the strap
  • Single, double or multiple strapping system through photocells
  • Strapping management through analog control panel
  • Enabling and disarming motorized steel rollers
  • Transit mode without strapping the product
  • Adjustment of motorized rollers’ speed on working table through potentiometer
  • Acustic alarm system with 3-color flashing column
  • Emergency stop button
  • Ejection loop in case of accidentally start of the cycle
  • 180 ° rotable control panel
  • Strap cutter
  • Height-adjustable working table
  • Automatic ejection of the strap at the end of the coil
  • Re-feed strap system
  • Works ith different strap sizes
  • Available with different dimensions of archs
  • Strapping tensioning adjustment up to 45 kg through potentiometer
Parametri regolabili da quadro comandi
  • Weld cooling time adjustment (COOL TIME)
  • Strap tension adjustment via potentiometer
  • Motorized rollers speed adjustment on the work surface
  • Temperature adjustment of the sealing blade
  • Enabling of single, double or multiple strapping, by means of photocells
  • Transit mode enabling without strapping
Product features
  • Max. Product dimensions: L 1200 x H 455 mm.
  •  Product weight: 80 Kg.
Strap roll features

Internal diameter: 200 – 210 mm.


External diameter: 400 – 450 mm.

Strap width: 9 – 12 mm.

Strap thickness: 0,45 – 0,65 mm.
Strap type: PP (polipropilene)

Scarica la scheda tecnica della reggiatrice

REQUEST A FREE QUOTE NOW

Make a request to receive our best offer on this product. Alternatively, for more information, you can always contact us at 06.9160.7561.

Additional information

Power supply

220 Volts

Power supply frequency

50/60 Hz

Installed power

1 Kw

Machine dimensions

L 1520 x W 680 x H 1460 mm.

Dimension strapping arch size

L 1050 x H 1000 mm., L 1050 x H 800 mm, L 1050 x H 800 mm., L 1250 x H 1000 mm., L 1250 x H 800 mm., L 1650 x H 600 mm., L 650 x H 500 mm, L 850 x H 500 mm., L 850 x H 600 mm., L 850 x H 800 mm.

Strapping speed

30 cycles/min.

Tension strength

0 – 45 Kg

Type

Motorized rollers

Control panel

Analog control panel

Max product weight

80 Kg

Reel internal diameter

200 – 210 mm.

Coil outer diameter

400 – 450 mm.

Strap width

9 – 12 mm

Strap thickness

0,45 – 0,65 mm

Strap type

PP (polypropylene)
