Speed Strap 505BP – 509BP – 512BP

In stock

REQUEST QUOTE NOW



High-performance automatic high-speed strapping machine suitable for insertion into packaging lines, guaranteeing high production rates as well as high standards of reliability. It has a strapping speed of 50 cycles per minute with a maximum adjustable tensioning force up to 45 Kg. The strapping machine is equipped as standard with a work table consisting of 8 motorized belts and a pneumatic press for product stabilization. Available on request with various measures of strapping arches.



Parametri reggiatrice ad alta velocità modello Speed Strap seire BP

Fully automatic high speed strapping machine with strapping unit equipped with 24 Volt brushless motors

The Speed Strap BP series is a compact and solid strapping machine equipped with a pneumatic stabilizing press and a working table made up of motorized conveyor belts. Regarding motorized conveyor belts, important improvements have been made, such as the addition of the central belt that allows to strap also products with small dimensions. In this version, the machine is equipped with standard photocells at the entry and exit of the product for the automatic execution of single, double or multiple strapping. Its features and performances make the machine suitable for high production rates and for those who need absolute reliability. The BP series is also available in the SUS 304 stainless steel version.

General characteristics of the strapping machine

The Speed ​​Strap fully automatic strapping machine uses a 220V power supply | 1 ph | 50/60 Hz and has an adjustable worktop height from H 870 to 970 mm. It has a strapping speed of 50 cycles per minute with a maximum adjustable tensioning force up to 45 Kg. The strapping machine is equipped with an integrated work surface with 8 motorized belts and 2 of reduced dimensions placed in the central part of the top, control panel 7.2 “touch screen, 2 photocells for the automatic execution of 1-2 or multiple straps, double pneumatic tamper for product stabilization, 3-color flashing column,” mode transit “function, without product strapping, system easyfast® strap guide disassembly (without tools).

There is also: automatic ejection of a piece of strap at the end of the reel, adjustment of the welding cooling time (COOL TIME), temperature adjustment of the sealing blade, strap cutting cutter, automatic strap loading system, magnetic safety sensors. The strapping machine is available on request with various arch sizes.

Layout reggiatrice Speed Strap 505BP

Features and parameters of the strapping machine

Technical characteristics of the strapping machine
  • Working table with motorized belt conveyor
  • Stainless steel safety handle
  • Double pneumatic top press
  • Safety guards with magnetic safety switches on each door
  • Automatic strap feeding
  • In & out signals displayed on the touch screen
  • Strapping group controlled by 24volt brushless motors
  • Single, double or multiple strappings
  • Transit mode without product strapping
  • Belts speed adjustable by inverter
  • Acoustic and 3 colors luminous signal
  • Loop ejection
  • 7,2’’ touch screen
  • Strap cutter device
  • Adjustable working table height
  • Four pivoting wheels, two of them with brake
  • Easyfast strap guide disassembly system (without any tool)
  • Automatic strap ejection at the end of the strap coil
  • Re-feed strap system
  • Possibility to use various strap sizes
  • Strap tensioning up to 45 kg
Parameters adjustable from the control panel
  • Strap tension adjustment
  • Temperature adjustment of the sealing blade
  • Management of “mode transit” function, without product strapping
  • Single, double or multiple strapping system adjustment
  • IN / OUT connection verification interface
Characteristics of the workable product
  • Max. Product dimensions: W 600 x H 450 mm. (with arch from L 650 x H 500)
  • Product weight: 30 Kg.
Features reel strap

Internal diameter: 200 mm.


External diameter: 400 – 450 mm.

Strap width: 5 – 9 – 12 mm.

Strap thickness: 0,45 – 0,65 mm.
Strap type: PP (Polypropylene)

Download the technical sheet of the strapping machine

REQUEST A FREE QUOTE NOW

Make a request to receive our best offer on this product. Alternatively, for more information, you can always contact us at 06.9160.7561.



Additional information

Power supply

220 Volts

Power supply frequency

50/60 Hz

Installed power

1 Kw

Air pressure

0.4 – 0.6 MPa

Machine dimensions

L 1414 x W 732 x H 1584 mm.

Dimension strapping arch size

L 650 x H 500 mm, L 850 x H 500 mm., L 850 x H 600 mm., L 850 x H 800 mm.

Strapping speed

50 cicli/min

Tension strength

0 – 45 Kg

Type

Momorized tapes and press

Control panel

Touch screen

Max product weight

30 Kg.

Reel internal diameter

200 mm.

Coil outer diameter

400 – 450 mm.

Strap width

5 – 9 – 12 mm.

Strap thickness

0,45 – 0,65 mm

Strap type

PP (polypropylene)
