Pallet Strap T45

In stock

REQUEST QUOTE NOW



Semi-automatic strapping machine model Pallet Strap T45 designed to meet the needs of strapping pallets. With easyfast® strap guide disassembly system (without tools), adjustment of the welding cooling time (COOL TIME), adjustment of the sealing blade temperature and adjustment of the length of the strap to be dispensed. Simple and practical to use.

Semi-automatic strapping machine for pallets

The new generation semiautomatic strapping machine, mod. PALLET STRAP T45, is suitable for any pallet strapping. It works with DC motors that control each function of the machine and has an electronic strap tensioning adjustable by potentiometer placed on the control panel. Compared to a traditional strapping machine, more than 30% of mechanical parts have been eliminated. It is equipped with a folding lance to facilitate the strap insertion under the pallet and a quick and easy vertical strapping.

General characteristics of the strapping machine

The Pallet Strap T45 uses a 220 V power supply | 1 ph | 50/60 Hz and has a folding lance to facilitate the insertion of the strap under the pallet. It has a strapping speed ranging from 10 to 15 cycles per minute with a maximum adjustable tensioning force up to 45 Kg. The strapping machine is equipped with 3 wheels, 1 of which is pivoting at the rear, necessary to facilitate the maneuverability of the machine. There is also: an easyfast® strap guide disassembly system, welding cooling time adjustment (COOL TIME), welding blade temperature adjustment, strap length adjustment to be dispensed.

Layout Pallet Strap T45

Features and parameters of the strapping machine

Technical characteristics of the strapping machine
  • Side working table in stainless steel
  • Robust strapping head
  • Electronic strapping tensioning
  • Strapping lance of length 1070mm
  • Minimum pallet height 350 mm
  • Motors only working during strapping cycle
  • Weight of the strapping machine 85 Kg
  • Strapping group with dc motors
  • Analog control panel
  • Maximum tensioning up to 45 kg
  • One back pivoting wheel
Parameters adjustable from the control panel
  • Adjustable cooling time
  • Adjustable strapping tensioning by potentiometer
  • Adjustable sealing blade temperature
  • Adjustable strap feeding length
Characteristics of the workable product
  • Min. Product dimensions: 350 mm
  • Product weight: No limit
Features reel strap

Internal reel diameter: 200 mm.

External diameter reel: 400 – 500 mm.
Coil width: 190 mm.
Strap width: 6 – 9 – 12 – 15 mm.
Strap thickness: 0,6 – 0,8 mm.
Strap type: PP (Polypropylene)

Download the technical sheet of the strapping machine

REQUEST A FREE QUOTE NOW

Make a request to receive our best offer on this product. Alternatively, for more information, you can always contact us at 06.9160.7561.

How did you find our Company??


Additional information

Power supply

220 Volt 1Ph

Power supply frequency

50/60 Hz

Installed power

0,25 kw

Machine size

L 760 x W 700 x H 1050 mm.

Strapping speed

10/15 cycles/min

Tension strength

3 – 45 Kg (adjustable)

Reel internal diameter

200 mm.

Coil outer diameter

400 – 500 mm.

Strap width

9 -12 – 15 mm.

Strap thickness

0,6 – 0,8 mm.

Strap type

PP (polypropylene)
