Speed Strap 505

In stock

REQUEST QUOTE NOW



High speed automatic strapping machine for medium / high production cycles. It works with 24Vdc brushless motors arranged for each function of the machine. It has a strapping speed of 65 cycles per minute with a maximum adjustable tensioning force up to 45 Kg. Available on request with various strapping arch sizes.



Features Speed Strap strapping machine

High speed automatic strapping machine

The new generation automatic strapping machines, Speed Strap 505 – 509 – 512 line have been developed in Europe. It is a compact and robust new technology strapping machine, for any strapping requirement of medium-high working capacity. It is a machine suitable for typography, post offices, banks and for any industry activity. It works with 24 Vcc brushless motors that control each function of the machine.

Compared to a traditional strapping machine, more than 30% of mechanical components have been eliminated. The high technology and the reduction of moving parts make the strapping head extremely reliable, reducing the maintenance costs. The strapping machine is equipped with a 180° rotating touch screen control panel (to work on both sides) and a strapping foot pedal to facilitate the start of the working cycle. Available also with pneumatic top press.

General characteristics of the strapping machine



Layout Speed Strap 505

Parameters of the strapping machine

Caratteristiche tecniche della reggiatrice
  • Stainless steel working table
  • Stainless steel safety handle
  • Magnetic safety switches
  • Optical sensor on the working table for automatic strap feeding
  • Strapping group with 24 volt vcc brushless motors
  • Automatic strap loading
  • Strap coil holder unlock by button
  • Loop ejection
  • 180° rotating touch screen control panel
  • Strap cutter device
  • Adjustable working table height
  • Four pivoting wheels, two of them with brake
  • Strapping foot pedal
  • Emergency stop button
  • Easyfast strap guide disassembly system (without any tool)
  • Automatic strap ejection at the end of the strap coil
  • Re-feed strap system
  • Adjustable cooling time
  • Various arches dimension available
  • Digital adjustment of strap tensioning up to 45 kg
Caratteristiche del prodotto lavorabile
  • Max. Product dimensions: W 600 x H 450 mm. (with arch of L 650 x H 500)
  • Max product weight: 25 Kg.
Strap roll features

Internal diameter: 200 mm.


External diameter: 400 – 450 mm.

Strap width: 5 – 9 – 12 mm.

Strap thickness: 0,45 – 0,65 mm.
Strap type: PP (Polypropylene)

Download the technical sheet of the strapping machine

REQUEST A FREE QUOTE NOW

Make a request to receive our best offer on this product. Alternatively, for more information, you can always contact us at 06.9160.7561.

How did you find our Company??


Scarica la scheda tecnica della reggiatrice

REQUEST A FREE QUOTE NOW

Make a request to receive our best offer on this product. Alternatively, for more information, you can always contact us at 06.9160.7561.

How did you find our Company??


Scarica la scheda tecnica della reggiatrice

REQUEST A FREE QUOTE NOW

Make a request to receive our best offer on this product. Alternatively, for more information, you can always contact us at 06.9160.7561.

How did you find our Company??


Easy Strap 309 – 312 – Easy Strap 309B – 312B  – Easy Strap 309BP – 312BP –  Easy Strap 309R – 312R – Easy Strap 309RP – 312RP

Additional information

Power supply

220 Volt 1Ph

Power supply frequency

50/60 Hz

Installed power

1 Kw

Machine size

L 1240 x W 630 x H 1460 mm.

Dimension strapping arch size

L 1050 x H 1000 mm., L 1050 x H 800 mm, L 1250 x H 1000 mm., L 1250 x H 500 mm., L 1650 x H 600 mm., L 650 x H 500 mm, L 850 x H 500 mm., L 850 x H 600 mm., L 850 x H 800 mm.

Strapping speed

65 cycles/min.

Tension strength

0 – 45 Kg

Type

Standard

Control panel

Touch screen

Reel internal diameter

200 mm.

Coil outer diameter

400 – 450 mm.

Strap width

5 – 9 – 12 mm.

Strap thickness

0,45 – 0,65 mm

Strap type

PP (polypropylene)
