Stretch wrapping machine Easy Wrap 2000 A WC

In stock

REQUEST QUOTE NOW


The Easy Wrap 2000 A WC model is a semi-automatic machine that allows palletised loads to be carried on the table by means of pallet. It is equipped with an electric stabilizer presser and the film is tensioned by a mechanical clutch (positioned on the upper part of the reel holder trolley) which can be manually adjusted by the operator. The machine is equipped with a PLC and 7.2 "color touch screen display.

WITH
OPERATOR

POWER
SUPPLY 1 kW

FILM
ROLL

PALLETIZED
LOAD





Fasciapallet semiautomatico a tavola aperta con pressino stabilizzatore del carico

Model Easy Wrap 2000 A WC is a semi-automatic machine for stretch-film wrapping of palletized loads: with electrical top press unit and with entry for transpallet for the easy loading of products with pallet track, the possibility to adjust the film tension by a mechanical brake or motorized prestretch, soft starting of the turntable by inverter, manual or automatic working cycle, the possibility to adjust the number of upward and downward rounds of the pallet. The machine is equipped with PLC and digital color display 7,2”.

Features and parameters

Features
  • Machine structure in painted steel sheet
  • Mast hinged at the base for easy and quick installation
  • Top press electrical unit
  • Film carriage by transmission chain
  • Turntable ø 1650 mm with entry for transpallet
  • Useful height 2000 mm
  • Environmental humidity conditions: ≤ 90%
  • Operating temperature range: + 0° C to + 40 ° C
  • Machine controlled by PLC and color 7,2” touch screen
  • Film carriage fall protection system
  • Safety photocell with entry for transpallet
  • Acoustic wearning at the cycle start
  • Mechanical brake
  • Ermegency stop in compliance with CE regulations
  • Back holes for forklifting of the machine
  • Inverter for soft start and indexed stop of the turntable
Parameters adjustable by control panel
  • Number of rounds in bottom
  • Number of rounds in top
  • Adjustable turntable speed from 0 to 12 rpm
  • Carriage ascending and descending speed
  • Photoeye reading delay adjustable
  • Carriage ascending and descending functions
  • Cycle Counter
Functions activated by control panel
  • Cycle ascending and descending
  • Cycle only ascending
  • Top sheet function with top and bottom cycle
  • N°08 programmable wrapping cycles
Characteristics of the workable product
  • Dimension max product: L 1000 x W 1200 mm.
  • Useful height: H 2000 mm.
  • Max weight product: 1200 Kg.
Film roll features

Film roll external diameters: 280 mm.

Film roll internal diameter: 76 mm.
Film roll height: 500 mm.
Film roll max weight: 20 Kg.

Download featuresSarica il layout PDF features Easy Wrap 2000 A WC

REQUEST A FREE QUOTE NOW

SAVE TIME! Make a request to receive our best offer on this product. Alternatively, for more information, you can always contact us at +39.06.9160.7561.

Additional information

Machine dimensions

L 2600 x W 1750 x H 2400 mm

Weight machine

700 Kg

Turntable diameter

1650 mm

Max load weight

1200 Kg

Turntable speed

0 – 12 (rpm)

Carriage up-down speed

1,4 – 4 (m/min)

Film tensioning

Mechanical brake

Maximum pallet dimensions

L 1000 x W 1200 x H 2000 mm

Power supply

220 Volt 1Ph

Power supply frequency

50/60 Hz

Installed power

1 Kw

Max dimension film roll

H 500 mm Ø 280 mm

Film roll max weight

20 Kg

Film roll thickness

12 – 35 (µm)

Photoeye to detect door height

std

Forklifting

Back
