Automatic strapping machine with pneumatic press

Automatic strapping machine with operator, Easy Strap 309P is a new generation automatic machine for strapping packages. It works with direct current motors arranged for each function of the machine. More than 30% of mechanical components have been eliminated compared to a traditional strapping machine. Robust and compact strapping machine, designed for general use and medium-high work volumes. 180° rotating control panel to work on both sides of the machine. Strapping pedal to facilitate the start of the cycle. Available in versions with pneumatic stabilizer press.

General characteristics of the strapping machine

The Easy Strap 309P automatic strapping machine uses a 220 V power supply | 1ph | 50/60 Hz and has an adjustable worktop height from H 875 to 975 mm. It has a strapping speed of 40 cycles per minute with a maximum tensioning force adjustable up to 45 Kg. The strapping machine is equipped with four pivoting wheels, two of which with brakes and an easyfast® strap guide disassembly system (without tools). There is also: automatic ejection of a piece of strap at the end of the reel, adjustment of the welding cooling time (COOL TIME), adjustment of the sealing blade temperature, strap cutting cutter, automatic strap loading system, magnetic safety sensors, etc. The strapping machine is available on request with various arc sizes.

Features and parameters of the strapping machine

Technical features

Stainless steel working table
Pneumatic press
Stainless steel safety handle
Magnetic safety switches
Strapping group with DC motors
Automatic strap loading
Strap coil holder unlock by button
Loop ejection
180° rotating analog control panel
Strap cutter device
Adjustable working table height
Four pivoting wheels, two of them with brake
Strapping foot pedal
Emergency stop button
Automatic strap ejection at the end of the strap coil
Re-feed strap system
Adjustable cooling time
Various arches dimension available
Adjustable strapping tensioning by potentiometer

Parameters adjustable from the control panel

Weld cooling time adjustment (COOL TIME)
Height-adjustable worktop
Strap tension adjustment via potentiometer
Sealing blade temperature adjustment

Caratteristiche del prodotto lavorabile

Max workable product dimensions: L 600 x H 450 mm. (with strapping arch L 650 x H 500)
Max product weight: 25 Kg.

Strap roll features

Internal diameter: 200 mm.

External diameter: 400 – 450 mm.

Strap width: 9 – 12 mm.

Strap thickness: 0,45 – 0,65 mm.

Strap type: PP (Polypropylene)

REQUEST A FREE QUOTE NOW

Make a request to receive our best offer on this product. Alternatively, for more information, you can always contact us at 06.9160.7561.

Additional information

Power supply frequency	50/60 Hz
Installed power	0,70 kW
Machine size	L 1240 x W 630 x H 1460 mm.
Dimension strapping arch size	L 1050 x H 1000 mm., L 1050 x H 800 mm, L 1250 x H 1000 mm., L 1250 x H 500 mm., L 1650 x H 600 mm., L 650 x H 500 mm, L 850 x H 500 mm., L 850 x H 600 mm., L 850 x H 800 mm.
Air pressure	6 bar
Strapping speed	40 cycles/min.
Tension strength	0 – 45 Kg
Control panel	Analog control panel
Reel internal diameter	200 mm.
Coil outer diameter	400 – 450 mm.
Strap width	9 – 12 mm
Strap thickness	0,45 – 0,65 mm
Strap type	PP (polypropylene)
